XLSX3-NS Series AC Servo Drives


Description

XLSX3-NS Series AC servo drives are designed for EtherCAT motion-control systems that need compact drive hardware with encoder feedback and cyclic control modes. The series spans small 50W axes through 1800W selections, covering natural-cooling and forced-cooling frames for different servo motor loads.

Common Parameters

ParameterSpecification
Input Power1PH AC220V, 50/60Hz
Encoder Support17-bit and 23-bit encoders
CommunicationEtherCAT
Control ModesCSP, CSV and CST
Protection LevelIP20
Operating EnvironmentIndoor use; altitude 2000m or below without derating, derating required above 2000m; avoid corrosive gases and liquids

XLSX3-NS1R1II / XLSX3-NS1R6I

ParameterSpecification
Rated Power50W, 100W, 200W
Rated Torque0.16Nm, 0.32Nm, 0.64Nm
Rated Speed3000rpm
Overload Capacity3 times rated load
Dimensions40 x 170 x 150 mm
Cooling MethodNatural cooling

XLSX3-NS2R8I / XLSX3-NS5R5I / XLSX3-NS7R6I

ParameterSpecification
Rated Power400W, 750W, 1000W
Rated Torque1.27-6.37Nm across the listed motor selections
Rated Speed3000rpm or 1500rpm by motor selection
Overload Capacity3 times rated load
Dimensions48 x 180 x 171 mm
Cooling MethodNatural cooling or forced cooling by selection

XLSX3-NS012I

ParameterSpecification
Rated Power1000W, 1300W, 1800W
Rated Torque8.28Nm, 11.46Nm, 14.64Nm
Rated Speed1500rpm
Overload Capacity3 times or 2.5 times rated load by selection
Dimensions80 x 170 x 196 mm
Cooling MethodForced cooling
