The NC100H Series Miniature Circuit Breaker is designed for AC 50Hz circuits, protecting single-pole 230V circuits and two-pole, three-pole or four-pole 400V circuits from overload and short circuit. It features high breaking capacity, rapid tripping and rail mounting.
Features
- Delicate appearance, light weight and reliable performance.
- High breaking capacity and rapid tripping.
- High fire-retarding and shock-resistant plastic enclosure and components.
- Suitable for infrequent making and breaking of electrical apparatus and lighting circuits.
Main Technical Parameters
- Type: NC100H.
- Poles: 1P, 2P, 3P and 4P.
- Rated current: 63A, 80A and 100A.
- Rated voltage: 230/400V for 1P, 400V for 2P/3P/4P.
- Rated short-circuit breaking capacity: 6kA.
- Conforms with IEC60947-2.
