The JMB Light Control Transformer uses separately wound primary and secondary windings. It is suitable for transformer applications that require control, lighting and indicator lamp windings, with winding capacity arranged according to the required circuit function.
Technical Character
- Primary and secondary windings are wound separately.
- When the secondary side has only one winding, it carries the rated transformer capacity.
- For secondary sides with control, lighting and indicator lamp windings, each winding is arranged according to its capacity.
- For simplex winding transformers with center taps, the center tap capacity should be lower than the rated transformer capacity.
Working Environment
- Altitude should not exceed 2500m.
- Ambient air temperature: -25C to +40C.
- Maximum average relative humidity in the dampest month: 90%.
- Use in places free from severe vibration, shock, rain or snow.
