| Part Number: | ULO | - | HC504 | - | B | 6 | 0 |
|---|---|---|---|---|---|---|---|
| Explanation: |
Brand ULO - ULO |
Model HC504 - 19-contact HDMI solder plug with extended rear shell |
Colour B - Black |
Shell Plating 6 - Tin |
Contact Plating 0 - Selective gold flash |
ULO-HC504 and ULO-HC505 are 19-contact HDMI male connectors for soldered wire termination. HC504 has an extended rear shell with cable-retention tabs; HC505 has a compact rear solder-terminal structure. Select the body arrangement and finishes for the intended cable assembly.
| Characteristic | Value | Models |
|---|---|---|
| Contact count / pitch | 19 / 0.5mm | Both |
| Termination | Solder | Both |
| Contact resistance | ≤50mΩ | Both |
| Insulation resistance | 100MΩ | Both |
| Dielectric withstand test | 100VAC for 1 minute | Both |
| Operating temperature | -20°C to +70°C | Both |
| Insulator | Thermoplastic, material group I, UL94V-0 | Both |
| Contact material | Copper alloy | Both |
Working voltage, current rating, cable diameter and wire size are unspecified. HDMI version, bandwidth and supported video formats are unspecified.
Both models use three ordering fields: insulator colour, shell plating and contact plating.
| Field | Code | Option |
|---|---|---|
| Insulator colour | B | Black |
| Shell plating | 6 / N | Tin / nickel |
| Contact plating | 0 | Selective gold flash |
| Contact plating | C | Selective 3µin gold |
| Contact plating | 1 | Selective 10µin gold |
Dimensions are in millimetres. The contact-face drawings identify positions 1, 2, 18 and 19, with distinct row-span references. The 100VAC electrical value is a dielectric test condition.
| Drawing reference | HC504 | HC505 |
|---|---|---|
| Overall length including rear features | 34.4 | 15.83 |
| Mating-shell width | 13.9 | 13.9 |
| Extended rear-shell width | 14.6 | Not applicable |
| Outer side-profile width | 5.2 | 6.45 |
| Inner side-profile reference | 4.45 | 4.45 |
| Upper contact-row span | 8 | 8±0.1 |
| Lower contact-row span | 9 | 9±0.1 |
| Adjacent stagger / spacing within a row | 0.5 / 1 | 0.5 / 1 |
| Additional contact-face width reference | Unspecified | 11.45±0.1 |
HC504 encloses the termination region within an extended metal shell and provides rear tabs for cable retention. Its complete outline is longer than HC505; use the individual drawing for rear clearance.
HC505 provides a compact shell and an exposed rear solder-terminal block. Its drawing includes both shell-present and insert views, plus the contact-face section references.
