The H2M-CV-2B cover closes the matching compact modular housing opening. Two projecting pegs engage the mating locking arrangement. Select the corresponding H2M housing interface and allow clearance for the pegs and locking mechanism.
| Property | Specification |
|---|---|
| Model | H2M-CV-2B |
| Cover material | Die-cast aluminium |
| Surface treatment | Powder coated |
| Colour | RAL 7037 grey |
| Locking interface | Two pegs; match the housing's plastic lever or screw locking arrangement |
| Plastic locking element material | PC, where fitted on the mating assembly |
| Seal | NBR |
| Limiting temperature | -40°C to +125°C |
| Flammability | UL 94 V0 for applicable non-metallic components |
| Protection | IP65 when correctly sealed and locked to the matching housing |
| Body dimensions | 44×39×41mm |
| Overall width across pegs | 57mm |
Keep the sealing face clean and seat the cover evenly before engaging the lock. Use the dimensional drawing to check surrounding clearance and the matching housing's locking features.
