GYFZ3 Distribution Box


Description

GYFZ3 distribution boxes use a metal cover and box made from cold-rolled steel plate with electrostatic spraying. The series is used for power distribution, control systems and protection-device installation where a compact metal enclosure is required.

Series Range

ModelSpecificationOverall dimensionsBottom box size
GYFZ3-44 way266*252*90 mm250*220*85 mm
GYFZ3-66 way266*252*90 mm250*220*85 mm
GYFZ3-88 way302*252*90 mm286*220*85 mm
GYFZ3-1212 way266*390*90 mm250*358*85 mm

Construction

  • Metal cover and box body.
  • Cold-rolled steel plate construction.
  • Electrostatic sprayed surface treatment.
