CLS50 single-color LED warning beacons offer red, yellow, green, blue or white indication with steady or flashing operation. Sound options include an intermittent beep or police-siren sound. Choose the supply and a screw, magnetic or L-shaped bracket mounting configuration.
SMD LEDs illuminate a PC lens above an ABS base. The typical life reference above 50,000 hours applies to high-brightness LED components, separately from complete-assembly life. The drawn body diameter is 61.5mm; the assembled body-height reference is 94mm, calculated from the 68.5mm upper section and 25.5mm lower section.
| Field | Code | Selection |
|---|---|---|
| Series | CLS | Single-color tower light |
| Size identifier | 50 | CLS50 family; drawn body diameter61.5mm |
| Color | R | Red |
| Y | Yellow | |
| G | Green | |
| B | Blue | |
| W | White | |
| Sound | Omitted | No sound |
| A | Intermittent beep | |
| C | Police-siren sound | |
| Light mode | T | Steady |
| W | Flashing | |
| Supply | J | 12VAC/DC |
| B | 24VAC/DC | |
| M | 220VAC | |
| Function | Omitted | Regular version; IP43 single-light protection |
| F | IP65 version | |
| K | Anti-interference version | |
| Mount | Omitted | Fixed screw installation |
| F | Magnetic mounting; specify its configuration separately | |
| E | L-shaped bracket | |
| Cable length | L02 | 0.2m |
| L1–L5 | L1 indicates1m; length is not limited to L5 | |
| Connection | Omitted | Free cable ends |
| M… | M-type connector; specify its complete configuration | |
| D… | DT-type connector; specify its complete configuration | |
| A… | AMP-type connector; specify its complete configuration | |
| S… | SM-type connector; specify its complete configuration | |
| Cable material | Omitted | PVC sheathed cable |
| U | PUR sheathed cable | |
| VP | Shielded PVC sheathed cable | |
| UP | Shielded PUR sheathed cable |
CLS50-R/CWB-EL02 selects a red flashing beacon with siren sound, 24VAC/DC supply, an L-shaped bracket and 0.2m cable. F in the function position specifies IP65; F in the mounting position specifies magnetic mounting.
All eight models below have a red lens, W flashing light and 0.2m cable. Other colors and steady operation are selected through the ordering options.
| Model | Sound | Supply | Mount |
|---|---|---|---|
| CLS50-R/WB-L02 | No sound | 24VAC/DC | Screw |
| CLS50-R/WM-L02 | 220VAC | ||
| CLS50-R/CWB-L02 | Police-siren sound | 24VAC/DC | |
| CLS50-R/CWM-L02 | 220VAC | ||
| CLS50-R/WB-EL02 | No sound | 24VAC/DC | L-shaped bracket |
| CLS50-R/WM-EL02 | 220VAC | ||
| CLS50-R/CWB-EL02 | Police-siren sound | 24VAC/DC | |
| CLS50-R/CWM-EL02 | 220VAC |
| Version | Rating condition | Maximum current | Power reference |
|---|---|---|---|
| CLS50 without sound | 12VDC | 42mA | 0.5W |
| 24VDC | 37mA | 0.9W | |
| 220VAC | 76mA | 1W | |
| CLS50-C siren | 12VDC | 50mA | 0.6W |
| 24VDC | 97mA | 2.4W | |
| 220VAC | 160mA | 2.7W |
Current and power references are stated separately. The ordering guide also lists an A intermittent-beep option; its separate current and sound-level ratings are not specified here.
| LED bead color | Bead voltage |
|---|---|
| Red | 1.8–2.2V |
| Yellow | |
| Green | 2.8–3.4V |
| Blue | |
| White |
Bead voltages describe LED components and are separate from the beacon's supply.
| Parameter | Specification |
|---|---|
| Maximum sound level | CLS50-C siren version: 90dB; measurement distance unspecified |
| Flashing frequency | 55–65 flashes/min; nominal60 flashes/min |
| Lens / base | PC / ABS |
| Cord specification | UL1007 |
| Installation screws | White plated finish |
| Ambient temperature | −30°C to +50°C |
| Relative humidity | ≤85% |
| Protection | Regular single light: IP43; F function option: IP65 |
| Altitude | ≤2000m |
| Compliance reference | Standard | Document reference |
|---|---|---|
| CE | EN61058 | Document number not specified |
Mounting brackets are purchased separately. Dimensions below are in mm. The light body comprises an upper 68.5mm section and lower 25.5mm section, giving a calculated assembled-body height of 94mm.
| Configuration / reference | Dimensions in mm |
|---|---|
| CLS50 screw mount / CLS50-MA fixing reference | Body diameter61.5; upper section68.5; lower section25.5; calculated body height94; three Ø3 fixing points onØ32.7 at120°; calculated adjacent-center spacing28.3 |
| CLS50 with E mount / CLS50-MC L-bracket reference | Body sections as above; bracket envelope97; vertical section97×72; projection30; Ø4 fixing reference; slots7.5×4.5 on42 centers |
Disconnect power before installation, wiring, work on the beacon or maintenance. Check the selected model and rated supply, secure the installation, exclude conductive dust and liquid, and protect wires from impact and abrasion. Seek qualified service for complex faults and high-voltage components.
These beacons are intended for industrial signaling. High-reliability infrastructure, personal-safety functions, harsh environments, fire or explosion hazards, military uses and aerospace projects require a specifically designed and expressly confirmed configuration.
