The C6-F21 Series is a fibre optic sensor amplifier for installations where the sensing point needs to be separated from the electronics by remote fibre probes. It provides selectable output modes, sensitivity functions and timer control for compact object-detection setups.
| Model / specification | C6-F |
|---|---|
| Output signal type | NPN / PNP |
| Output mode | Single output, dual output and analog output options |
| Output selection | LIGHT-ON / DARK-ON switch selection |
| Detection method | Light intensity detection with area detection and automatic sensitivity tracking |
| Light source | Red modulated light, 625nm |
| Response time | 200µs, 24ms or 25µs depending on mode |
| Timer function | One-shot, off-delay and on-delay timer functions |
| Timing range | 1-9999ms |
| Current consumption | ≤30mA |
| Protection circuit | Power reverse-polarity protection, overcurrent protection and overvoltage protection |
| Practical functions | Parameter initialization, key lock and two-point threshold setting |
| Material | Polycarbonate / plastic housing |
| Protection rating | IP67 |
| Operating temperature | -20°C to 55°C |
