C3961 and C3962 3.96 mm wire-to-wire connectors combine two- and three-position housings with matching terminals for compact cable assemblies. Nylon 66 UL94V-0 insulation is used for the housing variants, and the family supports up to 7 A per contact.
Select the two- or three-position housing by circuit count, then match the C3961 or C3962 terminal to the required mating half. Check the individual drawing for the contact orientation and crimp interface.
| Centerline | 3.96 mm |
|---|---|
| Positions | 2 and 3 |
| Rows | Single row housing options |
| Housing resin | Nylon 66 UL94V-0 |
| Maximum current | 7 A per contact |
| Maximum voltage | 300 VAC/DC |
| Wire range | 26–18 AWG |
| UL file | E364711 |
| Operating temperature | -25 °C to 105 °C |
| Contact plating | Tin Plating |
| Contact metal | Phosphor Bronze |
