B2541 is a 2.54 mm FPC header with a vertical surface-mount layout and 13 single-row positions. The black PBT UL94V-0 housing and tin-plated phosphor bronze contacts suit board-mounted cable interfaces.
Use B2541 on 1.2–1.6 mm PCBs. Confirm the land pattern, mating cable and assembly process against the drawing before production.
| Product role | Surface-mount vertical header |
|---|---|
| Centerline | 2.54 mm |
| Positions | 13 |
| Rows | Single row |
| Housing material | Black PBT UL94V-0 |
| Contact material and finish | Phosphor bronze, tin plating |
| Maximum current | 2 A per contact |
| Maximum voltage | 250 VAC/DC |
| Operating temperature | -40 °C to 125 °C |
| PCB thickness | 1.2–1.6 mm |
| UL file | E364711 |
| Packaging | Bag/carton |
