| Part Number: | ULO | - | HC05 | - | H6B | - | BK | - | 1L | - | MCV |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Explanation: |
Brand |
Housing Code HC05 - H6B housing |
Housing Size H6B - 6B panel mount base |
Housing Type BK - Panel mounting, bottom cable entry |
Locking Interface 1L - Single locking latch; all six sizes |
Protective Cover MCV - Aluminium die-cast cover; all sizes with 1L, or H10B, H16B and H24B with 4B |
These bottom-entry connector bases mount around a panel opening and provide a housing for the selected insert. Choose the housing size and locking arrangement together with the mating hood. Single latch, double latch and four-stud versions are distinct configurations. Protective covers are available on the model families listed below.
| Feature | Specification |
|---|---|
| Housing | Aluminium die-cast, powder-coated grey |
| Mounting and cable entry | Panel mounting, bottom entry |
| Housing seal | NBR |
| Limiting temperature range | -40°C to +125°C |
| Protection | IP65 according to IEC60529 for the coupled connector |
| 1L | One locking latch; galvanized/nickel-plated metal on 6B, 10B, 16B, 24B and 32B; stainless steel on 48B |
| 2L | Two fitted locking latches, galvanized/nickel-plated metal |
| 4B | Four locking studs for a double locking arrangement |
| Protective cover suffixes | CV: PC; MCV: aluminium die-cast. Replace XX only on a listed covered model family. |
Dimensions below are flange length × flange width × body height, following the labelled outline references. They exclude the latch and cover opening envelopes. Mounting hole dimensions refer to the panel unless a flange hole is explicitly identified. Keep the moving latch and cover clear of surrounding equipment.
| Model family or order code | Cover | Flange and body dimensions |
|---|---|---|
| ULO-HC05-H6B-BK-1L | None | 82.5×44.5×29.2mm |
| ULO-HC05-H6B-BK-1L-CV | PC | |
| ULO-HC05-H6B-BK-1L-MCV | Aluminium |
The covered options belong to the ULO-HC05-H6B-BK-1L-CV-MCV family. Both covered and uncovered bases use a 48×35mm panel cutout and four Ø4.4mm holes on 70×32mm centres. The latch opening sweep extends 20mm beyond the flange side. The covered base shows a 26mm cover projection and a 72.5mm opening sweep.
| Model family | Locking arrangement | Cover options | Flange and body dimensions |
|---|---|---|---|
| ULO-HC06-H10B-BK-1L | Single latch | None | 95×45×29.5mm |
| ULO-HC06-H10B-BK-1L-XX | CV or MCV | ||
| ULO-HC06-H10B-BK-4B | Four studs | None | |
| ULO-HC06-H10B-BK-2L | Double latches | ||
| ULO-HC06-H10B-BK-4B-XX | Four studs | CV or MCV |
All listed 10B bases use a 60×35mm panel cutout with four Ø4.4mm holes on 83×32mm centres. The flange holes are Ø4.5mm on 1L and 4B bases, including their covered options, and Ø4.4mm on the 2L base. Single latch opening clearance is 31mm beyond the flange side. The 2L base has a 55mm reference span across the latch pivots and a 9mm opening sweep beyond each flange end. The uncovered 4B base shows a 57.5mm reference span across its studs. Covered 1L and 4B bases show a 26mm cover projection and a 72.5mm opening sweep.
| Model family | Locking arrangement | Cover options | Flange and body dimensions |
|---|---|---|---|
| ULO-HC07-H16B-BK-1L | Single latch | None | 115.5×45×29.5mm |
| ULO-HC07-H16B-BK-1L-XX | CV or MCV | ||
| ULO-HC07-H16B-BK-4B | Four studs | None | |
| ULO-HC07-H16B-BK-2L | Double latches | 115×45×29.5mm | |
| ULO-HC07-H16B-BK-4B-XX | Four studs | CV or MCV | 115.5×45×29.5mm |
All listed 16B bases use an 82×35mm panel cutout and four Ø4.4mm holes on 103×32mm centres. The single latch opening sweep is 31mm beyond the flange side. The 2L base shows a 10mm opening sweep beyond each end and a 115mm flange length. Covered 1L and 4B bases show a 25mm cover projection and a 73mm opening sweep.
| Model family | Locking arrangement | Cover options | Flange and body dimensions |
|---|---|---|---|
| ULO-HC08-H24B-BK-1L | Single latch | None | 141×45.5×29.5mm |
| ULO-HC08-H24B-BK-1L-XX | CV or MCV | (140±1)×(43±0.5)×(29.5±1)mm | |
| ULO-HC08-H24B-BK-4B | Four studs | None | 141×45.5×29.5mm |
| ULO-HC08-H24B-BK-2L | Double latches | 139.5×42.5×29.5mm | |
| ULO-HC08-H24B-BK-4B-XX | Four studs | CV or MCV | 141×45.5×29.5mm |
The uncovered 1L, 4B and 2L bases and the covered 4B base show a 108×35mm panel cutout, with four Ø4.4mm holes on 130×32mm centres. The covered 1L base instead specifies fixing centres of (130±0.8)×(32±0.5)mm and does not separately dimension a panel cutout. Its flange and body dimensions retain the stated tolerances. The uncovered 1L base has a 31mm latch opening sweep. The covered 4B base shows a 25mm cover projection and a 73mm opening sweep.
| Model family | Locking arrangement | Cover options | Flange and body dimensions |
|---|---|---|---|
| ULO-HC09-H32B-BK-1L | Single latch | None | 124×90×34.5mm |
| ULO-HC09-H32B-BK-1L-XX | CV or MCV | ||
| ULO-HC09-H32B-BK-4B | Four studs | None | |
| ULO-HC09-H32B-BK-2L | Double latches |
All listed 32B bases use an 86×71mm panel cutout and four Ø5.5mm holes on 110×65mm centres. Single latch opening clearance is 50mm beyond the flange side. The covered 1L base shows a 26mm cover projection and a 110mm opening sweep. The 2L base has a 94.5mm reference span across the pivots and a 7mm latch opening sweep beyond each flange end.
| Model family | Cover options | Flange and body dimensions |
|---|---|---|
| ULO-HC10-H48B-BK-1L | None | 165×96×40mm |
| ULO-HC10-H48B-BK-1L-XX | CV or MCV |
The 48B bases use a stainless steel single latch, a 117×81mm panel cutout and four Ø6.4mm holes on 148×70mm centres. The latch opens 44mm beyond the flange side. The covered version shows a 110mm cover opening sweep on the opposite side.
