CJX2 Series AC contactors are built for switching motors and power-control circuits. CJX2-80 and CJX2-95 use the same coil-voltage range, mounting system, accessory platform and AC-3/AC-4 application categories, with the main selection difference being rated operating current.
Common Parameters
| Rated insulation voltage Ui | 690V |
|---|
| Rated working voltage | 400V |
|---|
| Rated control voltage | AC24V, AC36V, AC48V, AC96V, AC110V, AC127V, AC220V, AC380V |
|---|
| Ambient temperature | -5°C to +40°C |
|---|
| Auxiliary contacts | 1NC + 1NO |
|---|
| Utilization category | AC-3, AC-4 |
|---|
| Installation | Vertical mounting; screw mounting or 35mm/75mm standard rail mounting |
|---|
| Accessories | Auxiliary contact set, air-delay contact and mechanical interlocking mechanism |
|---|
| Overall dimensions | 96×129×127mm |
|---|
| Mounting dimensions | 40×100/110mm |
|---|
CJX2-80
| Rated operating current Ie | 80A |
|---|
CJX2-95
| Rated operating current Ie | 95A |
|---|
